Dbl or 4-side planer moulder Kupfermühle Vuin-plus 600
Technical details
ID: MS228
| Year | 1991 |
| Working width | 600 mm |
| Working height | 250 mm |
| Working height 4-side | 250 mm |
| Number of spindles | 4 |
| Spindle configuration | b-t-r+l |
| Spindle diameter | X-X-40-40 m m |
| Motor power | 11-15-11-11 kW |
| Working width adjustments | Digital adjustments |
| Working height adjustments | Digital adjustments |
| Feed speed | 30 m/min |
| Feed motor | 4 kW |
| Driven bed rollers | 3 |
| Infeed rollers | 4 |
| Outfeed rollers | 2 |
| Tools horizontal | Tersa Z4 |
| Constant table height | 800 mm |
| Champfering spindles | 2 x 1,85 kW |
| Weight | ca. 4500 kg |
| Dimensions | mm |
| Voltage | 400V 50Hz 3Ph. |
